M1 Specifications
Power Output continuous, 20 Hz to 20 kHz, <0.1% THD+N
8 Ω 1000 W
4 Ω 2000 W
3 Ω 2400 W
2 Ω >2000 W depending on line voltage regulation
With 120V AC supply the amplifier’s maximum output into impedances 4 Ω and lower, as well as its maximum duration, vary depending on line voltage regulation.
Frequency Response 20 Hz to 20 kHz
Open circuit +/- 0.1 dB
8 Ω +/- 0.1 dB
4 Ω +/- 0.1 dB
2 Ω +/- 0.2 dB
Power Bandwidth 1000 W at 8 Ω 5 Hz to 45 kHz
THD+N at 1 kHz, 8 Ω
1 W 0.01 %
10 W 0.01 %
100 W <0.03 %
1000 W <0.06 %
IMD 19 kHz + 20 kHz, CCIF 0.003%
S/N Ratio ref. 1000 W, IEC-A 113 dB
Voltage Gain 29 dB
Input Sensitivity 100 mV for 1 W output, 3.2 V for 1000 W output (8 Ω)
Input Impedance 10 kΩ (RCA), 20 kΩ (XLR)
Damping Factor 800 to 1400 depending on frequency
XLR Configuration Pin 1: Ground, Pin 2: Positive, Pin 3: Negative
POWER REQUIREMENTS
Consumption in a typical music/theater installation
standby mode, 120V mains <1 W
standby mode, 240V mains <2 W
operate mode, idle 33 W
